Maintenance Plans for CAT Forklift Model GC55KSTR

Integrate maintenance plans directly into your work orders in MaintainX.

1200 Hourly or 6 Monthly Forklift Maintenance

Powershift Transmission Change Oil and Wash Strainer

Steps

Hydraulic System Change Return Oil Filter and Wash Strainer

Steps

Differential Change Oil

Steps

Air cleaner Change Elements

Steps

Fuel Filter – Gasoline Change

Run this procedure

1 Month After Delivery of a New Truck

Replace hydraulic tank return oil filter

Replace gasoline fuel filter

Replace LP-Gas fuel filter

Retighten bolts and nuts of overhead guard

Run this procedure

200 Hourly or 1 Monthly Forklift Maintenance

Wheel nuts retightened

Differential oil level checked

Lift bracket raised and secured

Level/fill plug removed and cleaned

Lubricant level maintained to the bottom of the level/fill hole

Level/fill plug put back in place

Lift bracket lowered

Powershift transmission oil level checked

Floor plate removed

Run this procedure

10 Hourly or 1 Daily Forklift Maintenance

Check Damaged or faulty operation found the day before

Check Oil, fuel or coolant leaks

Check Lights

Check Load backrest extension

Check Tilt cylinder socket bolts

Check Overhead guard

Check Assist grip

Check Accelerator pedal

Check Brake pedal

Run this procedure

50 Hourly or 1 Weekly Forklift Maintenance

Warning: When using compressed air for cleaning, wear an approved face shield and protective clothing. Use maximum air pressure of 2 kgf/cm2 (30 psi) for cleaning purposes.

Notice: Never service the air cleaner with the engine running. Do not clean the elements by striking them against another object. Always inspect the element before and after cleaning. Use a light inside the element. Do not use elements with damaged pleats, gaskets or seals.

Park the lift truck on a level surface, with the forks lowered, the parking brake applied, the transmission in NEUTRAL and the engine stopped.

Caution: Install the dust pan with its arrow mark up.

Raise the hood.

Remove the dust pan by releasing the latches at three places.

Unscrew the wing nut, and remove the element by pulling it.

Remove the cover from the dust pan, and clean the inside of the pan by removing dust.

Clean the inside of the air cleaner housing.

Run this procedure
