Case Grader 865B

Warning: This maintenance check requires trained personnel with PPE!

Clean- Drain Transmission Screen (FUNK Transmission - 885B models)

Replace Transmission Oil (Note 4) (ZF Transmission - 845B / 865B models)

Replace Transmission Oil (FUNK Transmission - 885B models)

Replace Circle Turn Gear Housing Oil

Replace Alternator and Ar Conditioning Belts

Replace Air Cleaner Elements (See Air Cleaner System)

Lubricate Moldboard Lift Cylinder Pivots

Lubricate Moldboard Lift Cylinders Balls

Lubricate Moldboard Side Shift Cylinders Balls

Lubricate Articulation of Tilt Cylinders

Lubricate Moldboard Tilt Pivots

Lubricate Articulation Cylinders Pivots

Lubricate Articulation Bearings

Lubricate Drawbar Ball and Socket

Sign off on the grader maintenance

Warning: This maintenance check requires trained personnel with PPE!

Engine oil level (including filters)

Radiator (coolant level) (Note 3)

Transmission oil level (warm, engine running) (ZF and FUNK Transmission)

Differential Lock Oil Filter (if equipped)

Sign off on the grader maintenance

Replace Rear Axle Differential and Planetary Gear Oil (Graziano)

Replace Hydraulic System Oil (Note 5)

Adjust Turbocharger Fixing Bolts Torque

Sign off on the grader maintenance

Verify Alternator and Air Conditioner Belt

Lubricate Universal Joints and Drive Shaft

Verify Circle Turn Gearbox Oil Level

Replace Differential Lock Oil Filter (if equipped)

Lubricate Front Wheel Lean Bar Pivots

Lubricate Front Wheel Lean Cylinder Pivots

Lubricate Front Wheel Knuckle Lean Pivots

Lubricate Knucle King Pin Bearings
