Bobcat Loader 873

Empty spark chamber. (If equipped Spark Arrestor Muffler.)

Check battery for damage, hold down clamps, cables, connections and electrolyte level. Add distilled water as needed

Lubricate drive line Engine-to-Pump Coupler with multipurpose lithium based grease. (If equipped.)

Sign off on the 100 Hours Loader Maintenance

Steering Lever Pivots lubricated with multipurpose lithium based grease?

King Pins lubricated with multipurpose lithium based grease?

Engine / Hydraulic Drive Belt checked for wear or damage?

Fan Drive Gearbox fluid level checked and added if required?

Condition and tension of Other Drive Belts checked?

Function of Lift Arm By-Pass control in BISC checked?

Sign off on the 250 Hours Loader Maintenance

Replace fluid on Hydraulic Reservoir

Replace fluid on Final Drive Transmission (Chaincase On Wheel Machines Only)

Replace fluid (If required) in Track Roller, Idler Assemblies (Track Machines Only)

Replace Drive Motor Case Drain Filter (If equipped.)

Repack wheel bearings, grease internal splines in hub yoke. (Dealer Service Only) Wheel Bearing & Outer Splines (Aws Only)

Sign off on the 1000 Hours Loader Maintenance

Check level of engine oil and add as needed. Do not overfill.

Change oil and filter after first 50 Hrs

Check condition engine air filter indicator and/ or display. Service only when required. Do not use compressed air to clean elements

Check for leaks and damaged components of engine air system

Clean debris from grill, oil cooler and radiator of engine cooling system. Check coolant level cold; add coolant mixture if required

NOTE: above steps are done before starting the loader;
