Atlas Copco Oil-Injected Rotary Screw Compressor GA15VSD+

Check oil level. If needed, top up the oil

Check that condensate is discharged during operation

Compressor stopped and air outlet valve closed

Dirt on the condenser inlet removed with a vacuum cleaner

Condenser cleaned with an air jet in the reverse direction to normal flow using low pressure air

Compressed air nozzle kept more than 30 cm away from the condenser

Dust from inside the dryer removed, e.g. with a vacuum cleaner

Water or solvents not used to clean the condenser

Sign off on the condenser cleaning

Check coolers, clean if necessary

Remove the air filter element and inspect. Replace damaged or heavily contaminated elements

Check the filter elements of the electric cabinet. Replace if necessary

Warning: Ensure the compressor is stopped and voltage is switched off before proceeding.

Compressor stopped and voltage switched off?

Remove the cover of the air filter (AF) by turning it anti clockwise.

Fit the new element and the cover.

Reset the air filter service warning.

Compressor stopped and air outlet valve closed?

All parts under the coolers covered?

Service plate at the fan compartment removed?

Dirt removed from the coolers with a fibre brush?

Dirt removed from the fan with a fibre brush?

Cleaned with an air jet in the reverse direction to normal flow?
