Atlas Copco Oxygen Generator OGP 105

Safety Precautions: Close the generator's outlet valve and the air inlet valve and wait until machine working pressure is 0 bar. Switch off the generator. Always vent oxygen to the outside atmosphere. Due to fire hazard, smoking and the use of open flames are prohibited in the vicinity of the oxygen generator. Avoid closing valves too fast as gas velocities in the oxygen net might become too high, and create a hazardous situation.

Generator fully depressurized and purged with air to remove all oxygen?

Checked for damaged wiring or loose connections, and re-tightened?

Replaced the in- and outlet filter cartridges?

Replaced the activated carbon of the filter?

After maintenance activities, the service counter needs to be reset. Contact your supplier.

Sign off on the oxygen generator maintenance

Safety Precautions: Close the generator's outlet valve and the air inlet valve and wait until machine working pressure is 0 bar. Switch off the generator. Always vent oxygen to the outside atmosphere. Due to fire hazard, smoking and the use of open flames are prohibited in the vicinity of the oxygen generator. Avoid closing valves too fast as gas velocities in the oxygen net might become too high, and create a hazardous situation.

Generator fully depressurized and purged thoroughly with air to remove all oxygen before service or inspection?

Check for damaged wiring or loose connections, and re-tighten

Replace the in- and outlet filter cartridges

Replace the activated carbon of the filter

Replace the pneumatic valve(s) SV05. Use only oxygen approved grease.

Clean the filter of the electrical cabinet

Replace the pneumatic valves SV01 up to SV04

Safety Precautions: Close the generator's outlet valve and the air inlet valve and wait until machine working pressure is 0 bar. Switch off the generator. Always vent oxygen to the outside atmosphere. Due to fire hazard, smoking and the use of open flames are prohibited in the vicinity of the oxygen generator. Avoid closing valves too fast as gas velocities in the oxygen net might become too high, and create a hazardous situation.

Generator fully depressurized and purged thoroughly with air to remove all oxygen before service or inspection?

Check for damaged wiring or loose connections, and re-tighten

Replace the in- and outlet filter cartridges

Replace the activated carbon of the filter

Replace the pneumatic valve(s) SV05. Use only oxygen approved grease.

Clean the filter of the electrical cabinet

After maintenance activities, the service counter needs to be reset. Contact your supplier.

Generator's outlet valve and air inlet valve closed and machine working pressure is 0 bar?

Generator fully depressurized and purged thoroughly with air to remove all oxygen before service or inspection?

Oxygen vented to the outside atmosphere?

No smoking and the use of open flames in the vicinity of the oxygen generator?

Valves closed slowly to avoid high gas velocities in the oxygen net?

Generator set in Manual mode (Operation Mode)?

Generator's outlet valve and air inlet valve closed and machine working pressure is 0 bar?

Generator fully depressurized and purged thoroughly with air to remove all oxygen before service or inspection?

Oxygen vented to the outside atmosphere?

No smoking or use of open flames in the vicinity of the oxygen generator?

Valves closed slowly to avoid high gas velocities in the oxygen net?

Controller checked for information on the purity, alarms and service messages?
