ABB ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0503A-5 ACS880-07-0503A-5
Need answers fast?
Explore the manual using AI.
The ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0503A-5 is designed for efficient motor control and energy savings in industrial applications. This advanced drive offers robust performance, flexibility, and reliability, making it ideal for various automation needs. Optimize your operations with this high-quality frequency drive from ABB.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for ABB ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0503A-5 ACS880-07-0503A-5
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
ABB ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0503A-5 ACS880-07-0503A-5
Create an account to install this asset package.
Maintenance Plans for ABB ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0503A-5 Model ACS880-07-0503A-5
Integrate maintenance plans directly into your work orders in MaintainX.
6 Yearly ZCU-12 Control Unit Battery Replacement
Warning: For trained personnel only
Drive stopped
Electrical safety precautions followed
Battery ejector moved into the battery slot
Battery carefully pulled out of the battery holder
New CR2032 battery carefully put into the battery holder
Sign off on the battery replacement
1 Yearly Drive Maintenance
Performance quality of supply voltage
Inspect spare parts
Performance DC circuit capacitors reforming, spare modules and spare capacitors
Inspect IP22 and IP42 air inlet and outlet meshes
Inspect tightness of terminals
Inspect dustiness, corrosion and temperature
ABB-SACE Air circuit breaker maintenance
Sign off on the yearly drive maintenance
6 Yearly IP54 (UL type 12) Roof Fan 60 Hz Replacement
WARNING! Obey the safety instructions of the drive. If you ignore them, injury or death, or damage to the equipment can occur. If you are not a qualified electrical professional, do not do installation, commissioning or maintenance work.
Drive stopped and electrical safety precautions followed
Front and back gratings slid upwards and removed
Mounting screws of the upper cover removed and cover lifted off
Fan power supply wires disconnected
Mounting screws of the fan removed
Mounting screws of the fan cover removed
Fan lifted off
New fan installed in reverse order
20 Yearly Safety component Replacement
Warning: This procedure requires trained personnel with PPE!
Check if the mission time of functional safety components is expired
If the mission time is expired, proceed with the following steps
Choose the type of renewal
Note: Renewal of the components in the safety function circuit is economical only with larger drives that have replaceable circuit boards and other components such as relays.
Check if some of the components have already been renewed earlier
If some components have been renewed earlier, their mission time restarts. However, the remaining mission time of the whole circuit is determined by its oldest component.
Sign off on the safety component replacement
9 Yearly Cabinet “door" Fan Replacement
WARNING! Obey the safety instructions of the drive. If you ignore them, injury or death, or damage to the equipment can occur. If you are not a qualified electrical professional, do not do installation, commissioning or maintenance work.
Drive stopped and electrical safety precautions followed
Mounting plate above the fan removed
Four mounting screws of the fan mounting plate loosened
Mounting plate lifted upwards
Power supply wires unplugged
Fan mounting plate lifted off
Fan removed from the mounting plate
New fan installed in reverse order
Parts for ABB ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0503A-5 ACS880-07-0503A-5
Access the parts list for your equipment in MaintainX.
Fuse IEC
170M6412
Fuse UL
170M6412
Sine Filter
NSIN0900-6
Fuse IEC
SC32AR69V800TF
Fuse IEC
170M6412
Fuse UL
170M6412
Sine Filter
NSIN0900-6
Fuse IEC
SC32AR69V800TF
Fuse IEC
170M6412
Fuse UL
170M6412
Sine Filter
NSIN0900-6
Fuse IEC
