Trane CenTraVac™ Water-Cooled Chiller CVHF - 190-320 - 231 - 050L / 050L

Inlet guide vane linkage checked?

Painted surfaces cleaned and touched-up as needed?

Deteriorated, torn, or missing insulation repaired?

Perform Annual oil analysis (follow recommendations)

Clean and lubricate oil system as required

Run oil pump and check differential oil pressure

Sign off on the yearly oil system inspection

Shut down the chiller once each year to check the items of Starter or Adaptive FrequencyTM Drive

Check all connections per manufacturer specifications

Follow all manufacturer recommendations for starter or Adaptive FrequencyTM Drive (AFD) maintenance

Inspect/clean/service the AFD cooling system (water- or air-cooled AFD)

Record all applicable starter or starter component settings

Sign off on the yearly inspection

- Shut down the chiller once each year to check the items of Condenser

1. Inspect for fouling and scaling in tubes

2. Check operation of condenser water flow sensing device

3. Factory recommendation to eddy current test tubes every three years;

WARNING: Hazardous Voltage w/Capacitors!

Failure to disconnect power and discharge capacitors before servicing could result in death or serious injury.

Disconnect all electric power, including remote disconnects and discharge all motor start/run capacitors before servicing.

Follow proper lockout/tagout procedures to ensure the power cannot be inadvertently energized.

NOTICE: Check Purge Run-Time for Unit Hermetic Integrity!

Failure to follow instructions below could result in chiller damage.

If frequent purging is required, monitor purge pumpout rate, and identify and correct source of air or water leak as soon as possible to prevent moisture contamination caused by leakage.

NOTICE: Do Not Use Non-Compatible Parts or Materials!

Use of non-compatible parts or materials could result in equipment damage.
