Trane CenTraVac™ Water-Cooled Chiller CVHF - 190-320 - 215 - 050S / 050S

Use a non-destructive tube test to inspect the condenser and evaporator tubes

Tube test performed on condenser and evaporator tubes?

It may be desirable to perform tube tests on these components at more frequent intervals depending upon chiller application

This is especially true of critical process equipment

Ask your Sales account manager for a copy of engineering bulletin (CTV-PRB024*-EN) for clarification of the role of eddy current testing in chiller maintenance by providing information about eddy current technology and heat exchanger tubing

Sign off on the tube maintenance

Shut down the chiller once each year to check the items of Optional Accessories

If applicable, lubricate factory-installed gantries

After the first month of operation, inspect Heresite® or Belzona® coated waterboxes; thereafter, inspect as needed

Inspect and lubricate hinged waterboxes

With water flow sensing option, bleed tubing from waterboxes to transformers

Sign off on the yearly optional accessories maintenance

Inlet guide vane linkage checked?

Painted surfaces cleaned and touched-up as needed?

Deteriorated, torn, or missing insulation repaired?

Sign off on the exterior parts maintenance

Contact a qualified service organization to determine when to conduct a complete examination of the unit to discern the condition of the compressor and internal components

Check for evaporator water tube leaks

Check for condenser water tube leaks

Sign off on the yearly chiller maintenance

Lubricate the vane control linkage bearings, ball joints, and pivot points

Lubricate vane operator tang O- rings

Lubricate the oil filter shutoff valve O-rings

Sign off on the chiller lubrication
