Toyota Forklift 6FD20

Inspect clutch for abnormal sound and functioning

Inspect clutch master cylinder function and leak

Inspect transmission fluid level

Inspect transmission gear function and abnormal noise

Inspect for leaks in the differential

Measure tire inflation pressure of the wheels

Inspect for tire cuts, damage, and uneven wearing

Tighten for loose rim and hub nuts

Inspect for metal chips, pebbles, or foreign matter trapped in tire grooves

Inspect rim, side bearing, and disc wheel for damage

Inspect for abnormal sound and looseness in the front wheel bearing

Inspect for abnormal sound and looseness in the rear wheel bearing

Sign off on the drive system maintenance

Measure play and reserve in the brake pedal

Inspect the braking effect of the brake pedal

Inspect the operating force of the parking brake

Inspect the braking effect of the parking brake

Inspect for looseness or damage in the parking brake rod and cable

Inspect for leaks, damage, and mounting condition of the brake pipe

Inspect for leaks and fluid level in the reservoir tank

Measure clearance between drum and lining

Sign off on the braking system maintenance

Inspect cracks, damage and deformation of housing

Inspect cracks, damage and deformation of beam

Measure looseness of axle beam in vehicle longitudinal direction

Sign off on the drive system maintenance

Inspect cracks at fork root and welded part while forklift is new

Inspect wear and damage of mast support bushing

Inspect wear and damage of roller pins

Measure relief pressure in oil control valve

Inspect plug cord internal discontinuity

Inspect damage and cracks of frame, cross members, etc.

Sign off on the 2000 Hour / 12 Month Maintenance
