Toyota Forklift 5FD45

Inspect head guard for cracks at welded portions

Inspect head guard for deformation and damage

Retighten for loosening of mounting in the back-rest

Inspect back-rest for deformation, cracks, and damage

Inspect the function and mounting condition of the lighting system

Inspect the function and mounting condition of the horn

Inspect the function and mounting condition of the direction indicator

Inspect the functions of the instruments

Inspect the function and mounting condition of the backup buzzer

Measure injection timing in fuel system

Inspect draining of sedimenter in fuel system

Inspect oil clutch mechanism and leak

Measure stall and hydraulic pressure in torque converter and transmission

Clean clogging of relief valve filter

Clean hydraulic oil tank and oil strainer

Sign off on the 1000 Hour / 6 Month Maintenance

Engine oil filter replaced every 500 Hour / 3 Month

Engine coolant replaced every 500 Hour / 3 Month

Torque converter oil filter replaced

Hydraulic oil return filter replaced

Retighten loosening and damage of cylinder mounting

Inspect deformation and damage of rod, rod screw and rod end

Measure natural drop and natural forward tilt

Inspect for oil leaks and damage in the cylinder

Inspect for wear and damage of the pin and cylinder bearing

Inspect cylinder for uneven movement

Inspect for oil leaks and abnormal sound from the oil pump

Inspect clutch for abnormal sound and functioning

Inspect clutch booster function and leak

Inspect transmission fluid level

Inspect transmission gear function and abnormal noise

Inspect for leaks in the differential

Inspect for leaks in the torque converter and transmission
