Toyota Forklift 02-5FGE35
Need answers fast?
Explore the manual using AI.
The Toyota Forklift 02-5FGE35 is a reliable industrial asset designed for efficient material handling. Known for its robust performance and durability, this forklift model is ideal for various warehouse and manufacturing applications, ensuring optimal productivity and safety in operations.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Toyota Forklift 02-5FGE35
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Toyota Forklift 02-5FGE35
Create an account to install this asset package.
Maintenance Plans for Toyota Forklift Model 02-5FGE35
Integrate maintenance plans directly into your work orders in MaintainX.
2000 Hour / 12 Month Maintenance
Inspect cracks at fork root and welded part while forklift is new
Inspect wear and damage of mast support bushing
Inspect wear and damage of roller pins
Measure relief pressure in oil control valve
Inspect plug cord internal discontinuity
Inspect damage and cracks of frame, cross members, etc.
Retighten body bolt looseness
Sign off on the 2000 Hour / 12 Month Maintenance
1000 Hour / 6 Month Electric System Maintenance
Measure ignition timing
Measure battery fluid specific gravity
Inspect open-circuit in intake heater
Sign off on the electric system maintenance
2000 Hour / 12 Month Maintenance
Measure Valve clearance (IDZ-II·2Z)
Measure main body compression
Retighten cylinder head bolt loosening
Inspect muffler rubber mount
Measure injection nozzle injection pressure and spray status
Inspect radiator rubber mount
Retighten differential bolt loosening
2000 Hour / 12 Month Drive System Maintenance
Inspect cracks, damage and deformation of housing
Inspect cracks, damage and deformation of beam
Measure looseness of axle beam in vehicle longitudinal direction
Sign off on the drive system maintenance
2 Year Replacement
Power steering hoses replaced
Power steering rubbers parts replaced
Hydraulic hoses replaced
Fuel hoses replaced
Note: Chains are replaced every 3 years
Sign off on the 2 year replacement
