Terex Site Dumper TA400

Primary Fuel Filter/Water Separator Renew

Drive shaft Bearings Check oil level. Add if low

Brake Coolant Tank - Replace breather.

Parking Brake - Check pads and disc for wear. Adjust or replace if required. Test for proper function.

Thickness of pad friction material should never be allowed to wear below 3 mm (0.12 in).

Radiator Expansion Tank Check coolant level. Add if low

Drive Belt Visual Inspection for Damage

Engine Air cleaner Check. Renew element if required

Dropbox Check oil level. Add oil if low

Tyres Check condition and pressure

Filter/Water Separator Check. Drain as Required (T2 Only)

OCDB Tank Check oil level. Add oil if low

Walk Around Inspection - Inspect the machine as described in Section 4 of the operations manual.

Engine - Visually check the engine for damage, loose or frayed belts and listen for any unusual noises.

Differentials Drain oil and refill with new oil

Wheel Planetaries Drain oil and refill with new oil

OCDB Tank Drain oil and refill with new oil

Axles - Drain lubricant and refill to level plugs.

NOTICE: When refilling the centre axle, ensure that the 3rd differential unit is primed with 1 litre (1.75 UK pints) of oil before filling the drive head.;

Hydraulic Tank Drain oil and refill with new oil

Engine Air Cleaner Clean / renew filter element.

Cooling System Check Concentration

Turbocharger Mounting Nuts Check torque

Engine Mounting Bolts Check torque

Transmission Mounting Bolts Check torque

Articulation Pivot Nut Check torque

Drive Belt Tension Checked and Tightened If Required

Differentials Checked for Oil Level and Added If Low

Wheel Planetaries Checked for Oil Level and Added If Low

Articulation Bearings Lubricated

Oscillation Pivot Checked for End Float and Adjusted If Required

General Inspection - Checked Entire Vehicle for Leaks, Loose Bolts and Nuts or Damaged Parts. Examined the Vehicle, Particularly the Chassis, for Cracks or Broken Welds. Repaired Where Necessary.

Parking Brake - Checked Pads and Discs for Wear and Replaced Where Necessary. Tested for Proper Function.

NOTICE: This service interval applies to normal condition. Check the pads more frequently under more severe conditions.
