Stryker Stretcher 4402
Create an account to install this asset package.
Integrate maintenance plans directly into your work orders in MaintainX.
Gas Cylinder Replacement
Using a 1/8” hex wrench, remove the eight screws (F and G) that secure the column and drawer assembly to the top cradle bracket.
Using a T15 Torx driver, remove the four screws (E) and washers (D) that secure both columns to each valance bracket. Save the screws and washers.
Using 5/32” hex wrench, remove the eight screws (D) and washers (C) that secure the cylinder bracket to the top cradle bracket for the gas cylinder. Remove both sides. Save the screws and washers.
Using a rubber hammer, strike the top cradle bracket, near the gas cylinder to remove the cradle bracket from the gas cylinder.
Remove the cradle assembly and supports to gain access to the gas cylinder. Set aside the cradle assembly.
Lift up and remove the cabinet/drawer assembly. Set aside the cabinet/drawer assembly.
Using a 5/32” hex wrench, remove the two screws that secure the column support bracket. Save the screws.
Using a 3/16: hex wrench, remove the screw (AJ) and spacer (AH) from the lower guide tube. Save the screw and spacer.
Using the needle nose pliers, remove the gas cylinder clip. Save the clip.
Base Cover Replacement
Brakes applied
Product raised a few inches off the floor using a small jack
Two screws and two washers removed using a 5/32” hex t-handle
Repeat of step 1 and step 2 on the opposite end of the product
Jack removed
Entire column assembly raised off of the base assembly with the help of a second person
Assembly set securely out of the way
Base cover removed and discarded
Reverse to install
Cradle Top Cover Replacement
Brakes applied
Basket removed from the product
Two yellow basket pivot pins removed using a 3/16” hex wrench
Accessed the nuts that secure the basket trend catch to the top cover
Two nuts that secure the trend catch removed using a 3/8” nut driver
Both sides of the top cover cradle grasped and pulled up until the bottom and the top cover Velcro® separate
Cradle top cover removed and discarded
Reversed to install
Proper operation verified before returning the product to service
Drawer Slide Replacement
Brakes applied
Drawer pulled open
Two screws securing the drawer slide to the drawer removed using a T10 Torx driver and 5/16” wrench
Screw (E) and washer (F) securing the drawer slide to the column removed using a T15 Torx driver
Drawer opened from the opposite side and step 4 repeated
Drawer slide tab pulled out of the drawer from the open drawer
Drawer opened from the opposite side and step 6 repeated
Entire drawer slide assembly removed and discarded
Drawer slide assembly installed in reverse order
Cradle Bottom Cover Replacement
Apply the brakes
Remove cradle top cover
Remove the eight screws that secure the column and drawer assembly to the top cradle bracket
Remove the four screws that secure both columns to each valance bracket
Remove the two screws that secure each release handle to the top cradle bracket
Remove the four screws and washers from each cylinder bracket that secure the cylinder to the top cradle bracket
Strike the top cradle bracket, near the cylinder to disengage the bracket from the cylinder top
Flip the top assembly upside down
Remove the six screws and washers that secure the two valance brackets
Access the parts list for your equipment in MaintainX.
Internal tooth lock washer
0013-055-000
Cradle assembly
4402-010-002
Button head cap screw
0002-117-000
Mattress assembly
4402-031-001
Warning label, USA only
4402-010-921
Internal tooth lock washer
0013-055-000
Cradle assembly
4402-010-002
Button head cap screw
0002-117-000
Mattress assembly
4402-031-001
Warning label, USA only
4402-010-921
Internal tooth lock washer
0013-055-000
Cradle assembly
4402-010-002
Button head cap screw
0002-117-000
Mattress assembly
4402-031-001
Warning label, USA only
4402-010-921
