Stryker Stretcher 3333

Measure 4-3/8” from the top seam and 2-7/8” from the side seam of the backrest

Prick the fabric to find the hole for the screw on both sides

Locate the push bar onto the backrest with the bumpers oriented upwards

Install the top two screws without fully tightening so that the bracket is loose on both sides

Make sure that the bracket are square with the chair, use a scribe to pilot the bottom two holes

Install the two screws into the bottom holes and tighten. Also tighten the top two screws

Check proper functionality of the recliner prior to returning the recliner to service

Sign off on the push bar replacement

Apply the brakes on the recliner casters

Remove the four screws that attach the foot tray to the slide tubes using a screwdriver

Remove the eight screws that secure the foot tray casters to the foot tray using a Phillips screwdriver

Install the casters on the new foot tray and secure with the eight screws removed in step 3

Align the new foot tray mounting holes to the holes on the slide tubes

Attach the screws removed in step 2 and hand tighten

Push the foot tray in all the way

Tighten the four screws that hold the tray to the slide tubes using a Phillips screwdriver

Measure 15-1/4” from the bottom of the arm

Measure 23-1/2” from the front seam

Marked the location for the screw

Piloted the hole for the screw using a scribe

Located the I.V. pole onto the arm

Installed the bottom screw without fully tightening

Bracket is square with the chair

Piloted the other two holes using a scribe

Measure 4-3/8” from the top seam and 2-7/8” from the side seam of the backrest

Hole for the screw found and piloted on both sides

Push bar located onto the backrest

Top two screws installed without fully tightening

Two screws installed into the bottom holes and tightened

Measure 3/4” from the front seam of the arm

Measure 2-1/4” from the top of the arm

Pricked the fabric to find the hole for the screw

Located the side tray onto the arm

Installed the top front screw without fully tightening

Bracket is square with the chair
