Nidec Satellite Tracer LT-1000
Need answers fast?
Explore the manual using AI.
The Nidec Satellite Tracer LT-1000 is a high-performance industrial asset designed for precision tracking and control applications. This advanced model offers reliable operation and efficiency, making it essential for various manufacturing processes. Optimize your maintenance strategy with tailored procedures and essential spare parts for the LT-1000.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Nidec Satellite Tracer LT-1000
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Nidec Satellite Tracer LT-1000
Create an account to install this asset package.
Maintenance Plans for Nidec Satellite Tracer Model LT-1000
Integrate maintenance plans directly into your work orders in MaintainX.
Fuse Replacement
CAUTION! Be sure to turn the power off and disconnect the power cord from the outlet before replacing the fuses. Otherwise, electric shock may result.
Only the specified fuses (T 1 A 250 V) must be used. Any fuses other than the specified ones may cause fire.
Power turned off?
Power cord removed from the electrical outlet?
Power cord unplugged from the inlet?
Fuse holder under the inlet removed?
Fuses replaced with new ones?
Fuse holder put back into its original position?
Sign off on the fuse replacement
Satellite Tracer Cleaning
CAUTION: Never use an organic solvent such as paint thinner. It may ruin the surface of the tracer.
Lightly wipe the exterior of the LCD. Do not press the LCD using an object with a hard tip. In addition, keep magnetic objects away from the LCD.
Never use a sponge or cloth soaked in water. The water may leak into the inside of the tracer and cause instrument failure.
Is the cover or panel of the tracer dirty?
Upload a photo of the dirty tracer
Did you clean the tracer with a soft cloth?
For stubborn stains, did you soak the cloth in a neutral detergent, wring well, and wipe?
Did you dry the tracer with a soft, dry cloth?
Sign off on the tracer cleaning
Parts for Nidec Satellite Tracer LT-1000
Access the parts list for your equipment in MaintainX.
Fuse
804-02-02155
Fuse
804-02-02155
Fuse
804-02-02155
