Manitowoc Ice Machine RNF0320A-161

Manitowoc Ice Machine RNF0320A-161

Create an account to install this asset package.

Maintenance Plans for Manitowoc Ice Machine Model RNF0320A-161

Integrate maintenance plans directly into your work orders in MaintainX.

Equipment Exterior Cleaning

Check mark

Exterior Cleaning

Check mark

Wipe surfaces with a damp cloth rinsed in water to remove dust and dirt

Check mark

Is there any greasy residue remaining?

Check mark

Use a damp cloth rinsed in a mild dish soap and water solution if greasy residue persists

Check mark

Wipe dry with a clean, soft cloth

Check mark

Cleaning Precautions

Check mark

Ensure no steel wool or abrasive pads are used

Check mark

Ensure no chlorinated, citrus based or abrasive cleaners are used on exterior panels and plastic trim pieces

Run this procedureArrow right

6 Monthly Interior Maintenance

Check mark

Safety Precautions

Check mark

Wear rubber gloves and safety goggles (and/or face shield) when handling Ice Machine De-scaler or Sanitizer.

Check mark

Read and understand all labels printed on bottles before use.

Check mark

Preparation

Check mark

Remove front and top covers and set the toggle switch to the OFF position.

Check mark

Remove all ice from the bin.

Check mark

Turn off the ice making water supply and drain water from evaporator and reservoir.

Check mark

Remove the top cover from water reservoir.

Check mark

De-scaling Procedure

Run this procedureArrow right

6 Monthly Air-Cooled Condenser Cleaning

Check mark

Safety Precautions

Check mark

Disconnect electric power to the ice machine and the remote condenser at the electric service switch

Check mark

Condenser Cleaning

Check mark

Clean the outside of the condenser with a soft brush or a vacuum with a brush attachment

Check mark

Shine a flashlight through the condenser to check for dirt between the fins

Check mark

Is there dirt remaining between the fins?

Check mark

Use a suitable method to remove remaining dirt between the fins if necessary

Check mark

Modular Units Only

Check mark

Clean the washable filter with a mild soap and water solution

Run this procedureArrow right

Parts for Manitowoc Ice Machine RNF0320A-161

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

Metal Safe Ice Machine De-scaler

000000084

Sanitizer 16 oz.

9405653

Sanitizer 1 Gallon

9405813

Metal Safe Ice Machine De-scaler

000000084

Sanitizer 16 oz.

9405653

Sanitizer 1 Gallon

9405813

Metal Safe Ice Machine De-scaler

000000084

Sanitizer 16 oz.

9405653

Sanitizer 1 Gallon

9405813
