JCB Telehandler 533-105
Create an account to install this asset package.
Maintenance Plans for JCB Telehandler Model 533-105
Integrate maintenance plans directly into your work orders in MaintainX.
First 100 Hours Telehandler Maintenance
Coolant Quality and Level Check
Pre-Cleaner (if fitted) Check
Water Separator Check for contamination and Drain
Powertrain Mounting Bolts for Tightness Check
All Hoses - Condition Check
Transmission Mount Security Check
Transmission Oil Level Check
Transmission Oil Filter Change
Axle Mount Security Check
10 Hourly or 1 Daily Telehandler Maintenance
Coolant Quality and Level Check
Engine Oil level Check
Transmission Oil Level Check
Wheel Nut Security Check
Tyre Pressures/Condition Check
Wheel Alignment Check
Brake System Fluid Level(14) Check
Fire Extinguisher (if fitted) Check
Wing Mirrors Condition and Security Check
8000 Hourly or 8 Yearly Telehandler Maintenance
Cooling System Drain and Refill
Engine Oil and Filter(2)(3)(4) Change
Air Cleaner Dust Valve(5) Clean
Air Cleaner Outer Element(5) Change
Air Cleaner Inner Element Change
Water Separator Check for contamination and Drain
Water Separator Fuel Filter(8) Change
Engine Fuel Filter(5) Change
Front End Accessory Drive (FEAD) Belt Condition Check
2000 Hourly or 2 Yearly Telehandler Maintenance
Cooling System Drain and Refill
Engine Oil and Filter(2)(3)(4) Change
Air Cleaner Dust Valve(5) Clean
Air Cleaner Outer Element(5) Change
Air Cleaner Inner Element Change
Water Separator Check for contamination and Drain
Water Separator Fuel Filter(8) Change
Engine Fuel Filter(5) Change
Front End Accessory Drive (FEAD) Belt Condition Check
1000 Hourly or 1 Yearly Telehandler Maintenance
Coolant Quality and Level Check
Engine Oil and Filter(2)(3)(4) Change
Air Cleaner Dust Valve(5) Clean
Air Cleaner Outer Element(5) Change
Water Separator Check for contamination and Drain
Water Separator Fuel Filter(8) Change
Engine Fuel Filter(5) Change
Front End Accessory Drive (FEAD) Belt Condition Check
Powertrain Mounting Bolts for Tightness Check
Parts for JCB Telehandler 533-105
Access the parts list for your equipment in MaintainX.
JCB Engine Oil EP 15W40 10C to +50C (14°F to 122°F)
4001/1805
JCB Cold Climate Engine Oil EP5W40 -20C to +50C (-4°F to 122°F)
4001/2705
JCB Antifreeze HP/Coolant + Water (Refer to Coolant Mixtures)
4006/1120
JCB Transmission Fluid EP 10W(4) -32°C to 40C (-25°F to 104°F)
4000/2505
JCB Transmission Fluid EP SAE 30 -5°C to 46°C (23°F to 115°F)
4000/2605
JCB Engine Oil EP 15W40 10C to +50C (14°F to 122°F)
4001/1805
JCB Cold Climate Engine Oil EP5W40 -20C to +50C (-4°F to 122°F)
4001/2705
JCB Antifreeze HP/Coolant + Water (Refer to Coolant Mixtures)
4006/1120
JCB Transmission Fluid EP 10W(4) -32°C to 40C (-25°F to 104°F)
4000/2505
JCB Transmission Fluid EP SAE 30 -5°C to 46°C (23°F to 115°F)
4000/2605
JCB Engine Oil EP 15W40 10C to +50C (14°F to 122°F)
4001/1805
JCB Cold Climate Engine Oil EP5W40 -20C to +50C (-4°F to 122°F)
4001/2705
JCB Antifreeze HP/Coolant + Water (Refer to Coolant Mixtures)
4006/1120
JCB Transmission Fluid EP 10W(4) -32°C to 40C (-25°F to 104°F)
4000/2505
JCB Transmission Fluid EP SAE 30 -5°C to 46°C (23°F to 115°F)
