Hillphoenix Multi-Deck Merchandiser O5DM-NRG

DANGER! SHOCK HAZARD: Always disconnect power to case when servicing or cleaning.

Unplug the fan motor from the receptacle on the exterior of the fan plenum

Remove fasteners and lift out the entire fan basket

Re-install the fan basket and secure with fasteners

Plug the fan motor back into the receptacle on the exterior of the fan plenum

Disconnect power to the case before servicing or cleaning.

Ensure the ambient store temperature does not exceed 80°F.

Identify the lighting system type

Confirm that the new ballasts/power supplies are the correct replacement parts.

Turn off the ON/OFF switch located in the upper left-hand corner of the lighting assembly.

Simultaneously pull down at both ends of the old T-8 light to remove it from the lamp holder.

Disconnect power to the case before cleaning.

Ensure all electrical power is turned off, including multiple disconnect switches if applicable.

Check that the waste outlet is unclogged.

Lift the fan plenum to access the coil for cleaning.

Clean the coil and surrounding area, exercising caution to avoid sharp edges.

Shut off the lights in the case and wipe them down with a soft, damp cloth.

Pinch the latching clips inward at the ends of the luminaire

Rotate the luminaire down at each end until hooks are free

Place the hook into the shelf roll at the shelf front

Rotate the rear of the luminaire toward the shelf

Depress the rear clip so that the luminaire can finish rotating

Squeeze the plastic clips on the four-pin connector

Pull the connector free of the receptacle

Slide the luminaire to the opening

Disengage the luminaire from the metal housing slot

Engage the luminaire into the metal housing slot

Slide the luminaire into position

Connect the four-pin connector to the receptacle
