Hewlett Packard Management Module R0X31A

Ensure the replacement line module is available and ready to install.

Wear a properly installed ESD wrist strap to avoid damage to the line card.

Enter the slot ID for the module to be shut down.

Use the module <SLOT-ID> admin-state down command to bring down the module slot.

Verify the module is down using the show module <SLOT-ID> command.

Loosen the screws securing the line module to the chassis.

Put on an ESD wrist strap and connect it to the ESD connection point on the front of the chassis.

Ensure both management modules are installed

Identify and Switch Over Modules

Identify the active management module by checking the Mgmt State Actv LED for solid green.

Execute the redundancy-switchover command using the CLI and describe any issues encountered.

Did the Active/Standby conversion take place successfully?

Loosen the screws securing the module converted to Standby.

Put on an ESD wrist strap and connect it to the ESD connection point on the front of the chassis.

Identify Standby Management Module

Identify the standby Management module by checking the LEDs.

Remove Standby Management Module

Loosen the screws securing the standby module to the chassis.

Open the module levers and pull the module out of its slot.

Place the module in an anti-static bag to protect it from ESD damage.

Secure Slot if Not Installing New Module
