Maintenance Plans for Graco Spray Package Model 24V873
Integrate maintenance plans directly into your work orders in MaintainX.
Spray Package Maintenance
Care of the Pump
NOTICE: Do not allow the supply containers to run dry of the fluid being pumped.
Supply container is not dry
Throat packing reservoirs one-half filled with TSL
Pot life limit observed
System flushed when necessary
Fluid manufacturer’s instructions for fluid shelf life followed
System flushed with a compatible solvent
Pump flushed at higher cycle rates for better cleaning action
1 Daily Manual Lubrication
Warning: Disconnect the regulator before proceeding.
Regulator disconnected?
Place about 15 drops of light machine oil in the motor air inlet.
Oil placed in the motor air inlet?
Reconnect the regulator.
Regulator reconnected?
Turn on the air supply to blow oil into the motor.
Sign off on the daily manual lubrication
1 Daily Wet Cup Inspection
Wet Cup Maintenance
Is the wet cup one-half full with Graco Throat Seal Liquid (TSL)?
Enter the current level of Graco Throat Seal Liquid (TSL) in the wet cup
Is the level of Graco Throat Seal Liquid (TSL) maintained daily?
Sign off on the daily wet cup inspection
