Daikin Energy Recovery Ventilator VAM600GVJU

Remove the connector for electronic expansion valve (X7A) from PCB

Measure the resistance value between White and Yellow

No continuity between White and Yellow

Measure the resistance value between White and Orange

Resistance value between White and Orange is approx. 300 Ω

Measure the resistance value between White and Red

Resistance value between White and Red is approx. 150 Ω

Measure the resistance value between Yellow and Blue

Resistance value between Yellow and Blue is approx. 300 Ω

Check for High Pressure in cooling

Check for High Pressure in heating

Check for broken wire of the relay wire

Procedure for checking outdoor-outdoor unit transmission wiring for broken wires

Turn OFF the power supply to all equipment

Short circuit between the outdoor-outdoor unit terminal F1 and F2 in the 'Outdoor Unit A'

Conduct continuity checks between the transmission wiring terminal blocks F1 and F2 of the central remote controller using a multimeter

Warning: This procedure requires trained personnel with PPE!

Choose the type of vacuuming and dehydration

Vacuum pump enables vacuuming down to –100.7 kPa (–14.6 psi)?

Enter the vacuum pump run time in hours

Degree of vacuum reached –100.7 kPa (–14.6 psi) or less?

Leak tests conducted if vacuum did not reach –100.7 kPa (–14.6 psi) or less after 3 hours?

Compressor left at the degree of vacuum of –100.7 kPa (–14.6 psi) or less for a period of 1 hour or more?

Vacuum gauge reading did not rise after 1 hour?

Enter the amount of refrigerant charged

Warning: Ensure power is OFF before starting the procedure

All wiring removed from the PCB

Power supply turned OFF and 10 minutes or more have passed

Measurement mode for analog multimeter

Measurement in diode check mode for digital multimeter

Sign off on the power transistor check

Details of compressor capacity control while in cooling, refer to Compressor PI control

The low pressure protection control includes low pressure protection control and hot gas bypass control

In cooling, the indoor unit electronic expansion valve is used for superheated degree control

In heating, the outdoor unit electronic expansion valve is used for superheated degree control of outdoor unit heat exchanger
