Daikin Air Conditioner RN35CGXV19/CC01

Vacuum and Charge air conditioner

Is the outdoor unit provided with flare valve fittings?

Vacuuming The Piping And The Indoor Unit

Have you removed the caps from the valve and the service port?

Have you connected the center of the charging gauge to the vacuum pump?

Have you connected the charging gauge to the service port of the 3-way valve?

Have you started the vacuum pump and evacuated for approximately 30 minutes?

Has the charging gauge needle moved towards - 760mmg?

Caution: If the gauge needle does not move to - 760mmg, check for gas leaks at flare type connection of the indoor and outdoor unit and repair the leak before proceeding to the next step.

Describe the condition of the air filter after cleaning

Describe the condition of the indoor unit after cleaning

Check Indoor Fan for any abnormal noise

CAUTION: Avoid direct contact of any coil treatment cleaners on plastic part. This may cause plastic part to deform as a result of chemical reaction

Sign off on the air conditioner check

The unit is mounted solidly and rigid in position

Piping and connections are leak proof after charging

Drainage check: Pour some water into left side of drain pan (drainage are in right side of unit)

Conduct a test run after water drainage test and gas leakage test

Is the electric plug firmly inserted into the socket?

Is there any abnormal sound from unit?

Is there smooth drainage of water?

Condenser fan is running, with warm air blowing off the condensing unit
