Atlas Copco Stationary Air Compressor ZR30

WARNING! Never run the compressor without safety valves. No adjustments are allowed.

If safety valves are not present, stop the procedure and consult Atlas Copco.

Did the valve open at the pressure specified in section 7.2?

If the valve did not open at the specified pressure, consult Atlas Copco.

Sign off on the safety valve testing

Check coolers, clean if necessary

Compressor stopped and voltage switched off

Air filter cover removed and filter element removed

New element and cover installed

Service warning reset after carrying out the service actions of the related service plan

Stop the compressor and switch off the voltage

Remove filler plug (FC). Drain the compressor sump by opening drain valve (Dmo). Close the valve after draining

Remove the oil filter (OF). Clean the filter seat, oil the gasket of the new filter and screw it into place until the gasket contacts the seat. Then tighten by hand

Fill the compressor sump to the middle of the oil level sight-glass (SG) with oil

Run the compressor for a few minutes. Stop the compressor. If necessary, top up the gear casing with oil to the middle of the sight-glass (SG)

After carrying out the maintenance operations of the related service plan, the service warning must be reset

Sign off on the oil and oil filter change

Condensate discharged during loading?

Before starting, the level should be in the middle of the sight-glass

Sign off on the daily stationary air compressor check
