Atlas Copco Stationary Air Compressor ZT45

Condensate discharged during loading?

Before starting, the level should be in the middle of the sight-glass

Sign off on the daily stationary air compressor check

Warning: Always check the display and remedy the trouble if alarm LED is alight or blinks

Is the main screen indicating the compressor outlet pressure?

Is the status of the compressor displayed?

Are the functions of the keys below the display working?

Is the alarm LED alight or blinking?

Describe the alarm if it is alight or blinking

Is there a service message displayed?

Describe the service message if it is displayed

Did the compressor status check by pressing the ↓ key from the main screen pass?

Stop the compressor and switch off the voltage

Remove filler plug (FC). Drain the compressor sump by opening drain valve (Dmo). Close the valve after draining

Remove the oil filter (OF). Clean the filter seat, oil the gasket of the new filter and screw it into place until the gasket contacts the seat. Then tighten by hand

Fill the compressor sump to the middle of the oil level sight-glass (SG) with oil

Run the compressor for a few minutes. Stop the compressor. If necessary, top up the gear casing with oil to the middle of the sight-glass (SG)

After carrying out the maintenance operations of the related service plan, the service warning must be reset

Sign off on the oil and oil filter change

Check coolers, clean if necessary

Compressor stopped and voltage switched off?

Air filter cover removed and filter element removed?

Cover cleaned and filter element discarded?

New element and cover installed?

Service warning reset after carrying out the service actions of the related service plan?
