Traulsen Refrigerator UPT6024

Condenser Coil Inspection and Cleaning

Check the condenser coil for cleanliness

Ensure air can freely circulate through the condenser

Remove the lower rear panel on the rear of the equipment cabinet

Clean dirt and lint from the condenser coil using a vacuum cleaner or soft brush

Was a wire brush avoided during cleaning?

Use warm water, mild soap, and a soft cloth to clean the exterior.

Wipe in the direction of the metal grain.

Avoid using strong detergents and gritty, abrasive cleaners.

Ensure no cleansers containing chlorine are used.

Avoid splashing the unit with chlorinated water when mopping the floor.

For stubborn odors, use a baking soda and water solution (1 TBSP baking soda to 1 pint water).

Remove all food items from the refrigerator

Remove and clean all interior fittings

Prepare a baking soda cleaning solution

Clean the interior surfaces with the baking soda solution

Clean the breaker strips and door gaskets with the baking soda solution

Disconnect electrical power supply

Remove the lower panel at the rear of the equipment cabinet

Flush evaporator coil, condensate loop, and condensate pan with fresh water

Clean the condensate removal box

Reassembly and Power Restoration

Reconnect electrical power supply
