Sartorius Electronic Precision Scales EA6DCE-L

Open the electronics module (see page 11)

Unplug the load-cell cable from the main PCB

Select the model type for specific instructions

Remove the strain-relief clamp in the electronics module (2 Phillips screws)

Save the 2 rubber cable guides for later reassembly

Calibration/Adjustment Sequence

Check and adjust the following factors

Select 'Diagnostics' program in service software

Select 'High Resolution' subprogram

Read off the weight value on the Psion server or PC display

Activate 'Close' function in service software to reset scale to SBI mode

Disconnect the scale from the power supply

Remove or cut the wire tie holding the cable that connects the electronics module to the display and control unit

Unplug the display PCB cable from the main PCB

Cable Removal for DCE and EDE Models

Release the strain-relief clamp in the electronics module (2 Phillips screws) and remove the cable

Use the service software to read out and store the scale’s data record, if possible.

Order a pre-programmed PCB if data record cannot be stored, indicating the scale model and serial number.

Disconnect the scale from the power supply.

Remove the pan support from the strain-gauge load cell
