Hussmann Open Fish Sevice Case DSFN-EP-3-R

CAUTION: DO NOT TEAR THE HONEYCOMB

Describe the condition of the honeycomb after removal

Amount of powdered detergent used in tablespoons

Describe the condition of the honeycomb after cleaning

Sign off on the honeycomb removal & cleaning

Warning: This maintenance check requires trained personnel with PPE!

Is the discharge honeycomb clean?

Is there any accumulated dirt in the condenser coil?

Is there any accumulated dirt in the condensate evaporator pan?

Poor circulation of air through the condenser coil will result in poor refrigeration performance.

Is there poor circulation of air through the condenser coil?

Dirt accumulation inside the condensate evaporator pan will reduce the pan’s capacity and affect the efficiency of the heater causing a burned out heater and an overflow of defrost water onto the store floor.

Is there dirt accumulation inside the condensate evaporator pan?

Is the power supply to the equipment reliable?

WARNING! ALWAYS DISCONNECT THE ELECTRICAL POWER AT THE MAIN DISCONNECT WHEN SERVICING OR REPLACING ANY ELECTRICAL COMPONENT OF THIS REFRIGERATOR. THIS INCLUDES, BUT IS NOT LIMITED TO SUCH ITEMS AS FANS AND THERMOSTATS.

The evaporator fan is located directly under the deck pan.

ALWAYS REPLACE THE FAN BLADE WITH THE RAISED EMBOSSING SIDE OF THE BLADE INSTALLED TOWARD THE MOTOR.

Sign off on the fan blade replacement

Warning: Shut off fan before cleaning. Do not use water hoses, chlorinated cleaner, abrasives or steel wool scouring pads, cleaning or sanitizing solution that has an oil base or an ammonia base.

Interior bottom wiped with domestic soap or detergent based cleaners?

Exterior cleaned with water and a mild detergent?

Interior wiped with damp non-abrasive cloth?

Sanitizing solution used to eliminate bacteria?

Visible debris surrounding or on top of the drain location cleaned?

All surfaces scrubbed thoroughly with soap and hot water?

Rinsed with hot water without flooding?

1. The high optical clarity of this glass is possible due to special coatings on the glass surface itself.

2. To preserve this coating and the optical clarity, keep the glass clean. 3. Water is the only solution recommended to be used to clean the non-glare glass.

4. The damage to the glass from improper, caustic solutions is irreparable.

5. In addition to cleaning the glass with the recommended product, there are precautions that should be taken when working and cleaning the inside of the case.

• When cleaning the inside of the cases, we recommend that the glass be fully opened and covered to prevent to prevent solutions from splashing onto the glass and ruining the coating on the inside.;
