Hussmann Merchandiser With Hinged Doors ARV-400

Warning: Ensure the thermostat is in the 'OFF' position. This disconnects the condensing unit only.

Note: The evaporator fan motor will be energized until the door is opened or the unit is disconnected from the main power source.

Is the evaporator fan motor de-energized?

Remove the fasteners to lower the evaporator housing for cleaning and/or service.

Have the fasteners been removed and the evaporator housing lowered for cleaning and/or service?

Note: Evaporator fan will cycle 'OFF' during defrost cycle. Evaporator fan will delay approximately 5 to 10 minutes after each defrost cycle and initial start-up on Low Temperature Models (ARL's).

Has the evaporator fan cycled 'OFF' during the defrost cycle?

Enter the delay time of the evaporator fan after each defrost cycle and initial start-up on Low Temperature Models (ARL's).

Sign off on the evaporator housing maintenance.

• Long life and satisfactory performance of any equipment is dependent upon the care given to it.

• To ensure efficient operation, proper sanitation and minimum maintenance, the cabinet should be thoroughly cleaned, debris removed and the interior cleaned regularly.

CAUTION! TO AVOID PERSONAL INJURY OR DAMAGE TO ELECTRICAL COMPONENTS, ALWAYS DISCONNECT UNIT FROM MAIN POWER SOURCE BEFORE SERVICING OR CLEANING

Cabinet Surfaces (Interior and Exterior)

• To preserve finish, the cabinet should be cleaned with a mild solution of soap and warm water only, using a soft cloth or sponge.

• DO NOT use any type of caustic soap, abrasive cleaner, or steel wool scouring pads which can mar the cabinet finish.;

The air cooled condenser should be cleaned regularly. A dirty condenser restricts air flow, causing decreased refrigeration efficiency. (Clean every month or as required).

With main power supply disconnected, remove louver grill from front of lower cabinet. Most dirt will collect on the air intake side of the condenser. This is opposite the fan motor.

Use a bristle brush to loosen the dust and dirt and remove with a vacuum cleaner. When cleaning condenser line beware of fin edges as they are sharp.

If the merchandiser is located in an area susceptible to grease collecting on the condenser, scrub with a solution of warm water and detergent. Care should be taken to keep solution away from wiring and electrical components.

Take the fan guard out for fan blades and condenser shroud cleaning, then re-install the fan guard (optional).

Check for loose items before replacing panel.

Sign off on the condenser cleaning
