Hatco Food Cabinet FSDT-2

Turn off the unit and unplug the power cord

Perform the Draining the Water Reservoir procedure

Fill the water reservoir with a mixture

Set both the air temperature and humidity to their highest settings

Lift the glass panel out of the bottom channel of the cabinet

Pull the lower edge away from the cabinet

Carefully lower the glass until the top clears the cabinet

Position the glass panel with the top edge under the top cabinet lip, and raise the glass until it clears the bottom channel of the cabinet

Move the bottom of the glass towards the cabinet until the glass rests against the cabinet frame

Carefully lower the glass until it rests in the bottom channel of the cabinet

Turn off the unit and unplug the power cord.

Allow the unit to cool before cleaning.

Wipe down all interior and exterior metal surfaces with a damp cloth.

Use a non-abrasive cleaner for stubborn stains.

Clean hard to reach areas using a small brush and mild soap.

Clean the glass side panels and door panel(s) with glass cleaner and a damp, soft cloth or paper towel.

Select the model of the rotating rack being removed

Pull down the spring-mounted coupling to compress

Tip the rack until the rack shaft clears the motor shaft

Ensure the bow cotter pin is not removed from the rack shaft

Insert the rack into the cabinet and place the rack bottom point in the dimple located at the center of the cabinet floor

Pull down the spring-mounted coupling to compress

Turn off the unit and unplug the power cord

Locate the valve inside the cabinet on the underside of the ceiling sheet

Position a one gallon (four liter) container under the valve

Turn the valve handle to the vertical position to open

Return the valve handle to the closed position once the reservoir is empty
