Fairbanks Horizontal Split-Case Pump 5" 2876

Unbolt and remove the glands away from the packing

Use a packing hook to remove the worn packing and water seal rings

Note the location of the water seal rings relative to the amount of packing on each side of the rings

Clean the packing boxes and shaft sleeves

Inspect the shaft sleeves for wear or rough finish and replace if necessary

Stop the pump and remove the pipe plug at the bottom of the bearing housing.

Connect a grease gun to the lubrication fittings.

Inject grease until it relieves at the bearing housing cover and drain hole.

Start the pump and monitor bearing temperatures until they stabilize.

Stop the unit, wipe off the relieved grease and replace the drain plug.

Start the unit and resume normal operation.

Loosen the gland nuts to allow adjustment with finger pressure

Is there a small flow of liquid to lubricate the packings?

Packing Inspection and Adjustment

Has the flow of liquid increased?

Add one ring of packing to the stuffing box if necessary

Readjust the gland after adding packing

Does the flow reduce after adjustment?

Lock out the power to the driver and close the suction and discharge valves.

Disconnect and remove the coupling or flexible shafting.

Disconnect and remove all auxiliary piping to the upper casing and bearing housings.

Remove the capscrews securing the upper casing half to the lower half.

Remove the gland nuts and slide the glands off the gland studs.

Install jackscrews in the tapped holes in the upper half casing flange and use them to separate the flanges.

CAUTION: READ THIS ENTIRE PROCEDURE BEFORE PROCEEDING.

Thoroughly clean all parts to remove oil, grease, and foreign material.

Inspect parts for wear or damage and replace if required.

Move all parts to a clean and dust-free location for assembly.

Replace gaskets, grease seals, and bearings with new parts.

Impeller Wear Rings Replacement

Select the method for securing impeller wear rings
