Emglo Products Air Compressor K15A–8P

Warning: Hot surfaces. Risk of burn. Aftercooler, pump head, and surrounding parts are very hot, do not touch (see the Hot Surfaces identified in Fig. 2). Allow compressor to cool prior to servicing.

Ensure On/Off switch is in the OFF position.

Remove air compressor plug from outlet.

Allow air compressor to cool down before starting service.

NOTE: All compressed air systems contain maintenance parts (e.g., oil, filters, separators) that are periodically replaced. These used parts may contain substances that are regulated and must be disposed of in accordance with local, state, and federal laws and regulations.

NOTE: Take note of the positions and locations of parts during disassembly to make reassembly easier.

NOTE: Any service operations not included in this section should be performed by an EMGLO factory service center or an EMGLO authorized service center.

NOTE: Pump oil contains substances that are regulated and must be disposed of in accordance with local, state and federal laws and regulations.

Ensure On/Off switch is in the OFF position.

Remove air compressor plug from outlet.

Allow air compressor to cool down before starting service.

Take note of the positions and locations of parts during disassembly to make reassembly easier.

The air compressor flywheel and motor pulley must be in-line (in the same plane) within 1/16\ (1.6 mm) to ensure belt retention within flywheel belt grooves."

Place a straightedge (U) against the outside of the flywheel (R) and the motor drive pulley (S).

Measure the distance between the edge of the belt (T) and the straightedge at points A1 and A2 in Figure. The difference between mea­sure­ments should be no more than 1/16\ (1.6 mm)."

Warning: Hot surfaces. Risk of burn. Aftercooler, pump head, and surrounding parts are very hot, do not touch (see the Hot Surfaces identified in Fig. 2). Allow compressor to cool prior to servicing.

Ensure On/Off switch is in the OFF position.

Remove air compressor plug from outlet.

Allow air compressor to cool down before starting service.

NOTE: All compressed air systems contain maintenance parts (e.g., oil, filters, separators) that are periodically replaced. These used parts may contain substances that are regulated and must be disposed of in accordance with local, state, and federal laws and regulations.

NOTE: Take note of the positions and locations of parts during disassembly to make reassembly easier.

NOTE: Any service operations not included in this section should be performed by an EMGLO factory service center or an EMGLO authorized service center.

Remove six belt guard mounting screws (two on the pump head and four on the deck)

Safety Warning: Ensure On/Off switch is in the OFF position before starting the procedure.

Safety Warning: Remove air compressor plug from outlet before starting the procedure.

Safety Warning: Drain air tank before starting the procedure.

Safety Warning: Allow air compressor to cool down before starting service.

NOTE: All compressed air systems contain maintenance parts (e.g., oil, filters, separators) that are periodically replaced. These used parts may contain substances that are regulated and must be disposed of in accordance with local, state, and federal laws and regulations.

NOTE: Take note of the positions and locations of parts during disassembly to make reassembly easier.

NOTE: Any service operations not included in this section should be performed by an EMGLO factory service center or an EMGLO authorized service center.

Warning: Hot surfaces. Risk of burn. Aftercooler, pump head, and and surrounding parts are very hot, do not touch (see the Hot Surfaces identified in Fig. 2). Allow compressor to cool prior to servicing.

Warning: Risk of bursting. If the safety valve does not work properly, over-pressurization may occur, causing air tank rupture or an explosion.

Warning: Ensure On/Off switch is in the OFF position.

Remove air compressor plug from outlet.

Allow air compressor to cool down before starting service.

Warning: Hot surfaces. Risk of burn. Aftercooler, pump head, and surrounding parts are very hot, do not touch. Allow compressor to cool prior to servicing.

Follow procedures 1-6 in Checking Belt Tension under Maintenance.

Scribe a mark at the base of the pump on the deck to be used as a reference.

Loosen four pump mounting nuts.
