Daikin Screw Chiller AWV030

Create an account to install this asset package.

Maintenance Plans for Daikin Screw Chiller Model AWV030

Integrate maintenance plans directly into your work orders in MaintainX.

Microchannel Aluminum Coils Cleaning

WARNING: Prior to cleaning the unit, turn off and lock out the main power switch to the unit and close all access panels.

Did you turn off and lock out the main power switch to the unit and close all access panels?

Surface loaded fibers or dirt should be removed prior to water rinse to prevent further restriction of airflow.

Choose the method used to remove surface loaded fibers or dirt

NOTE: Use of a water stream, such as a garden hose, against a surface loaded coil will drive the fibers and dirt into the coil. This will make cleaning efforts more difficult.

Did you avoid using a water stream against a surface loaded coil?

High velocity water from a pressure washer or compressed air should only be used at a very low pressure to prevent fin and/ or coil damages.

Did you use high velocity water or compressed air at a very low pressure?

No maintenance is ordinarily required except the routine removal of dirt and debris from the outside surface of the fins.

Run this procedure

Screw Chiller Lubrication

Warning: Handle POE oil with proper protective equipment (gloves, eye protection, etc.)

Fan motor bearings noise check

CAUTION: Avoid prolonged exposure of refrigerant to the atmosphere

Select the type of POE oil used

Compressor oil heater is functioning properly?

Sign off on the lubrication procedure

Run this procedure

3 Monthly Epoxy Coated Coils Cleaning

Warning: This cleaning procedure requires trained personnel with PPE!

Quarterly cleaning is essential to extend the life of an epoxy coated coil and is required to maintain warranty coverage.

Surface debris removed from the coil?

Coil cleaned with an approved coil cleaner?

Select the cleaning agent used

Soluble salts removed with CHLOR*RID DTS?

Coil rinsed properly?

Warning: Harsh chemicals, household bleach or acid cleaners should not be used to clean epoxy coated coils.

Sign off on the coil cleaning

Run this procedure

1 Yearly Screw Chiller Maintenance

Annual (or spring startup) operations include all weekly and monthly operations.

General:

- Inspect thermal insulation for integrity

- Clean and paint as required

Electrical ( * including the VFDs):

- Sequence test controls

- Check contactors for pitting, replace as required

- Check terminals for tightness, tighten as necessary

- Clean control panel interior

Run this procedure

Electrical Terminals Check

DANGER: Electric equipment can cause electric shock which will cause severe personal injury or death. Turn off, lock out and tag all power before continuing with following service. Panels can have more than one power source.

CAUTION: Periodically check electrical terminals for tightness and tighten as required. Always use a backup wrench when tightening electrical terminals.

Power turned off, locked out and tagged?

Electrical terminals checked for tightness

Backup wrench used when tightening electrical terminals

Sign off on the electrical terminals check

Run this procedure
