Daikin Air Handler CAH017GDGC

Warning: This procedure requires trained personnel with PPE!

Belt tension slacked off if belts have been installed

Capscrews E loosened but not removed

Pitch diameter adjusted by opening or closing the movable flanges by half or full turns

Setscrews D and capscrews E tightened

Belt tension readjusted if belts have been installed, or belts installed and tension adjusted if not previously installed

CAUTION: Sharp fin edges are a potential injury hazard. Avoid contact with them

To obtain maximum performance, the coil must be clean

Check once a year under normal operating conditions and, if dirty, brush or vacuum clean.

Use a chemical coil cleaner on multiple row coils

Read and follow the chemical cleaner's instructions as some cleaners may contain harsh chemicals

Take care not to damage fins while cleaning.

Check all moving parts for wear

Check bearing collar, sheave, and wheel hub setscrews, sheave capscrews, and bearing hold-down bolts for tightness

Inspect for signs of water damage such as corrosion and repair if necessary

Check ground conductor and connection integrity and correct if needed

Annually check and snug all electrical connections

WARNING: Before servicing fans, lock out and tag out all power to the unit. Fans or belts can cause severe personal injury or death

WARNING: Do not open the hinged access door and screw-fastenerd access panels while the unit is operating. Moving parts and strong suction forces can cause severe personal injury or death

Replace the variable pitched motor sheave with a properly sized, fixed sheave

Replace the adjustable sheaves with fixed sheaves

Measure the diameter of the V-belt outer surface where it passes around the sheave (pitch diameter)

Calculate fan speed from the motor nameplate rpm

Sign off on the fan drive maintenance

Adjust motor base forward to release belt tension

Remove the belts for easier adjustment

Loosen, but do not remove both of the locking setscrews A in the outer locking ring by using a hex key or torque wrench with a hex bit

Adjust sheave to desired pitch diameter by turning the outer locking ring, using a spanner wrench or drift inserted into the three holes that are located 120° apart on the ring

Ensure pitch diameter is within the sheave range. One complete turn of the outer locking ring changes the pitch diameter 0.233

Tighten BOTH locking screws A in the outer locking ring before operating the drive. Use a torque wrench and tighten to the value

Replace belts and adjust the motor base to tension the belts properly

Do not loosen any screws other than the two locking screws A in the outer locking ring when adjusting the sheave pitch. Do not operate the drive until the locking screws have been set to the torque specifications
