Boss Heat Pump Celsius Platinum

1 Check installation of the whole heat pump and the pipe connections according to the pipe connecting drawing

2 Check the electric wiring according to the electrical wiring diagram and earthing connection

3 Make sure that the main power is well connected

4 Check if there is any obstacle in front of the air inlet and outlet of the heat pump.;

1 The user is advised to start the water pump before the heat pump, and turn off the heat pump before the water pump for long life circle.

2 The user should start the water pump, and check for any leakage of water; power on and press the ON/OFF button of the heat pump, and set desired temperature in the thermostat.

3 In order to protect the heat pump, the heat pump is equipped with start delay function. When starting the heat pump, the fan will start to run in 3 minutes, in another 30 seconds, the compressor will start to run.

4 After pool heat pump starts up, check for any abnormal noise from the heat pump.

5 Check the temperature setting.;

1 Regularly clean the evaporator with household detergents or clean water.

NEVER use gasoline, thinners or any similar fuel.

2 Check bolts, cables and connections regularly.

3 Every three months spray a surface insecticide on the surfaces around the unit to prevent and and insect ingress.

In climates where the winter season reaches sub-zero temperatures, please disconnect from power supply and drain water out of the heat pump. When using the heat pump under 2°C, make sure there is always water flow.;
