Apollo Safety Valve 19S

CAUTION! Before testing, make certain discharge pipe is properly connected to valve outlet and arranged to contain and safely dispose of discharge

CAUTION! Hot, high pressure fluid may be discharged from body drain during lever test.

CAUTION! High sound levels may be experienced during lever test. Wear proper safety equipment and exercise extreme care.

Under normal operating conditions in steam service, has the pressure test been performed annually?

In air/gas service, has the pressure test been performed every 3 years?

Under severe service conditions or if corrosion, pitting, and/or deposits are noticed within the valve body, has testing been performed more often?

Test at or near maximum operating pressure by holding the test lever fully open for at least five seconds to flush the valve seat free of sediment and debris. Was this done?

Then release lever and permit valve to snap shut. Was this done?

If lift lever does not actuate, or there is no evidence of discharge, was the equipment turned off immediately?

CAUTION! Before testing, make certain discharge pipe is properly connected to valve outlet and arranged to contain and safely dispose of discharge

CAUTION! Hot, high pressure fluid may be discharged from body drain during lever test.

CAUTION! High sound levels may be experienced during lever test. Wear proper safety equipment and exercise extreme care.

Discharge pipe properly connected to valve outlet?

Sign off on the safety valve test

CAUTION! Before testing, make certain discharge pipe is properly connected to valve outlet and arranged to contain and safely dispose of discharge

CAUTION! Hot, high pressure fluid may be discharged from body drain during lever test.

CAUTION! High sound levels may be experienced during lever test. Wear proper safety equipment and exercise extreme care.

Discharge pipe properly connected to valve outlet?

Arrangements made to safely dispose of discharge?

Safety equipment worn during lever test?
