The ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0124A-5 is designed for optimal motor control and energy efficiency in industrial applications. This versatile drive offers advanced features for precise speed regulation and is ideal for various automation tasks, ensuring reliable performance and reduced operational costs.

Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0124A-5

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents & Manuals

Find all the essential guides in one place.

Tensioning Guide
Belt-diagram
C-120 pulleys
+ 13 more

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

Daily Electrical System Inspection
Replace Roller and Pulley
Install Engine B-120
+ 29 more

Procedures

Integrate maintenance plans directly into your work orders.

Motion Industries
Applied Industrial Technologies
Electrical Brothers
+ 5 more

Parts

Access the parts list for your equipment in MaintainX.

Drive Motor
B2 Rollers
Tensioning System
+ 40 more

ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0124A-5

Create an account to install this asset package.

Maintenance Plans for ABB Enclosed Variable Speed/Frequency Drive Model ACS880-07-0124A-5

Integrate maintenance plans directly into your work orders in MaintainX.

6 Yearly ZCU-12 Control Unit Battery Replacement

Warning: For trained personnel only

Drive stopped and electrical safety precautions taken

Battery ejector moved into the battery slot on the battery

Old battery carefully pulled out of the battery holder

New CR2032 battery carefully put into the battery holder

Sign off on the battery replacement

Run this procedure

ZCU-12 Memory Unit Replacement

Warning: Do not remove or insert the memory unit when the control unit is powered.

Drive stopped and electrical safety precautions followed

Upload a photo of the memory unit before removal

Clip at the side of the memory pulled up

Memory unit removed

Upload a photo of the memory unit after removal

Memory unit installed in reverse order

Upload a photo of the memory unit after installation

Sign off on the memory unit replacement

Run this procedure

9 Yearly Cabinet Fan Replacement

Warning: Follow the steps in section Electrical safety precautions before you start the work.

Drive stopped?

Fan mounting plate removed?

Fan removed from the mounting plate?

New fan installed in reverse order?

Sign off on the fan replacement

Run this procedure

9 Yearly IP54 (UL type 12) Roof Fan 50 Hz Replacement

WARNING! Obey the safety instructions of the drive. If you ignore them, injury or death, or damage to the equipment can occur. If you are not a qualified electrical professional, do not do installation, commissioning or maintenance work.

Stopped the drive and did the steps in section Electrical safety precautions before starting the work.

Lifted the front grating upwards and removed it.

Loosened the fastening screws of the front plate. Removed the plate.

Disconnected the fan supply wires.

Loosened the mounting screws of the fan.

Pulled the fan out.

Installed the new fan in reverse order.

Sign off on the fan replacement

Run this procedure

9 Yearly Auxiliary Cooling Main Fan Replacement

Drive stopped and electrical safety precautions followed

Power supply wires unplugged from the control unit terminal X208:FAN2
